Maximum capacity:4000kg
Maximum height:14m
Engine power:85kw
Maximum height:14m
Engine power:85kw
Telehandlers will take your material handling productivity to new heights. Telehandlers offer the extended reach and superior lift capacity of a heavy-duty telescoping boom combined with a range of attachments. It will quickly become your go-to machine for farming and ranching applications, construction, landscaping, snow removal, and much more.
Telehandlers are designed durable – and built to last – with a combination of tough construction, high-quality materials and features that maximize reliability. Look to the rigid frame, sealed engine compartment and side-by-side cooling design and know it’s ready for the most severe conditions.
| Model | HWR4014 |
| Engine | Yuchai |
| Power | 85KW |
| Emission Standard | National II emission standard |
| Overall Weight | 13000kg |
| Rated Load | 4t |
| Maximum Lifting Height | 14m |
| Overall Dimensions (L*W*H) (mm) | 6400x2350x2550mm |
| Hydraulic Oil Capacity | 170L |
| Fuel Tank Capacity | 195L |
| Telescopic Boom | Three-section |
| Telescopic Boom Material | BS1000 high-strength manganese plate |
| Towing Fork | 1220mm sliding trailer fork |
| Maximum Travel Speed | 40 km/h |
| Hydraulic Operating System | Electro-hydraulic load-sensitive proportional system |
With their compact size, lift capacity, maneuverability and attachment versatility, there’s little that telehandlers can’t do. Adding one to your fleet can help you take your business to new heights.
